maserati qtp v6 evoluzione getrag transmission 6 speed: outside controls parts diagram

027 - Getrag Transmission 6 Speed: Outside Controls

Maserati QTP V6 Evoluzione Getrag Transmission 6 Speed: Outside Controls Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Price
# 001
MPN: 325253300
GEARSHIFT LEVER BOOT
- Valid for M.T. version
from £20.62
from £20.62
# 002
MPN: 167200625
SCREW
- Valid for M.T. version
from £2.46
from £2.46
# 003
MPN: 14488601
WASHER
- Valid for M.T. version
from £1.17
from £1.17
# 004
MPN: 375280102
KNOB
- Valid for M.T. version
from £119.51
from £119.51
# 005
MPN: 325253185
CONTROL LEVER
- Valid for M.T. version - Up to assembly 1021 - Until supplies last, CPL 375290100 will be - supplied thereafter
Supersession
Supersession
This part replaces part number 325253172
# 005
MPN: 385200185
CONTROL LEVER
- Valid for M.T. version - From assembly 1022
from £55.53
from £55.53
# 006
MPN: 325253569
CUP
- Valid for M.T. version
from £11.76
from £11.76
# 007
MPN: 16104421
SELF LOCKING NUT
- Valid for M.T. version
from £0.81
from £0.81
# 008
MPN: 13507001
WASHER
- Valid for M.T. version
from £0.94
from £0.94
# 009
MPN: 325253180
SUPPORT
- Valid for M.T. version
from £13.08
from £13.08
# 010
MPN: 375290150
GEARSHIFT CONTROL ROD
- Valid for M.T. version - From assembly 1022
from £386.93
from £386.93
# 010
MPN: 395250150
GEARSHIFT CONTROL ROD
- Valid for M.T. version - Up to assembly 1021
Supersession
Supersession
# 011
MPN: 325253564
WASHER
- Valid for M.T. version
from £1.47
from £1.47
# 012
MPN: 325253572
CLIPS
- Valid for M.T. version
from £1.07
from £1.07
# 013
MPN: 325253176
ARTICULATION
- Valid for M.T. version
from £421.62
from £421.62
# 014
MPN: 315232407
GASKET
- Valid for M.T. version
from £1.93
from £1.93
# 015
MPN: 395250301
Frame
- Valid for M.T. version
from £10.08
from £10.08
# 016
MPN: 325253302
SPONGE RUBBER PROTECTION
- Valid for M.T. version
from £4.62
from £4.62
# 017
MPN: 16044121
SCREW
- Valid for M.T. version
from £0.71
from £0.71
# 018
MPN: 12613077
LOCK WASHER
- Valid for M.T. version
from £0.84
from £0.84
# 019
MPN: 325253178
PIN WITH CLIPS
- Valid for M.T. version
from £14.08
from £14.08
# 020
MPN: 395250574
BRACKET
- Valid for M.T. version
from £121.87
from £121.87
# 021
MPN: 325253568
BUSH
- Valid for M.T. version
from £9.61
from £9.61
# 022
MPN: 325253566
LEVER
- Valid for M.T. version
from £6.24
from £6.24
# 023
MPN: 375208577
BUSH
- Valid for M.T. version
from £5.93
from £5.93
