44.03.00 - Exhaust System
Lamborghini Diablo 6.0 (2001) Exhaust System Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 008200614
NUT
Supersession
Supersession
# 002
MPN: 004435003
SHIELD
from £3,086.78
from £3,086.78
# 003
MPN: 009444151
WASHER
Supersession
Supersession
# 004
MPN: N10158604
SCREW
from £16.26
from £16.26
# 005
MPN: 008400623
WASHER
Supersession
Supersession
# 006
MPN: N01020717
SCREW
from £0.48
from £0.48
This part replaces part number 008100504
# 007
MPN: 008410508
WASHER
from £0.48
from £0.48
# 008
MPN: 004437428
SUPPORT
from £55.17
from £55.17
# 009
MPN: N90179103
WASHER
from £0.98
from £0.98
This part replaces part number 008400801
# 010
MPN: 008410806
WASHER
Supersession
Supersession
# 011
MPN: N01100845
NUT
from £1.21
from £1.21
This part replaces part number 008200801 - and 2 more. Click to view details
# 012
MPN: 008401006
WASHER
from £0.51
from £0.51
# 013
MPN: 008451005
WASHER
from £0.50
from £0.50
# 014
MPN: N10155210
NUT
from £1.25
from £1.25
This part replaces part number 008201001
# 015
MPN: 400251393A
EXHAUST SUPPORT MOUNT
from £151.23
from £151.23
This part replaces part number 004432031 - and 5 more. Click to view details
# 016
MPN: 004430979
SILENCER
from £1,522.50
from £1,522.50
# 017
MPN: 004425084
THREADED HALF RING
from £283.61
from £283.61
# 018
MPN: 004424070
BI-CONE RING
from £93.82
from £93.82
# 019
MPN: N0444416
STUD
from £2.18
from £2.18
# 020
MPN: 004425084
HALF RING
from £283.61
from £283.61
# 021
MPN: 008440806
WASHER
use : WHT001185
Supersession
Supersession
# 022
MPN: N02214621
NUT
from £1.39
from £1.39
This part replaces part number N0221468
