011 - Cooling System

      Key

      STPart in stock.SOPart available to order (subject to availability).
      PSAvailable in a part set.PSAvailable in a part set to order (subject to availability).
      PKAvailable in a part kit.PKAvailable in a part kit to order (subject to availability).
      #
      Part number
      Description
      Price
      # 001
      PN: 001710067
      COOLAN PIPE
      TUBO RAD.DES/SERB/SUPPL./C
      from £85.96
      RH RADIATOR/SUPPLEMENTARY RESE RVOIR PIP Genuine Lamborghini - New (to order)
      # 002
      PN: 001711395
      TUBE
      TUBO RAD.DES/TUBO SCOCCA
      from £14.58
      RH RADIATOR PIPE/CHASSIS PIPE Genuine Lamborghini - New in stock
      # 003
      PN: 008830204
      CLAMP RING
      FASC. ROYAL A/ 5 7/11
      from £4.22
      # 004
      PN: 001728844
      RADIATOR
      RADIATORE DESTRO FINO A VETT. N. 1435
      from £2,091.60
      # 004
      PN: 001728844
      RADIATOR
      RADIATORE DESTRO DALLA VETT. N. 1436
      from £2,091.60
      # 005
      PN: 001724564
      FLANGE
      FLANGIA PER TERMOCON . SUL RADI
      from £83.32
      RADIATOR THERMAL CONTACT FLANG E Genuine Lamborghini - New (to order)
      # 006
      PN: 001724511
      GASKET
      GUARNIZ.PER TERMOC . COM . MOT . VEN
      from £12.70
      FAN MOTOR THERMOCOUPLE SEAL Genuine Lamborghini - New (to order)
      # 007
      PN: 008100831
      BOLT
      BULL.M8X30 UNI 5737/8G
      from £0.47
      SCREW M8X30 UNI 5737/8G/Z Genuine Lamborghini - New (other) in stock
      Bull.MSxSO UNI 5737/8G
      # 008
      PN: 001724565/A
      Thermocontact
      (two terminals)
      from £75.00
      # 009
      PN: 008200402
      NUT
      DADO 4MA OTTONE
      from £1.54
      # 010
      PN: 008410402
      LOCK WASHER
      ROND. A 4,3 UNI 1751 C72
      from £0.47
      # 011
      PN: WHT001942
      WASHER
      ROND. 0.8,5X32X2, 5
      from £1.77
      # 012
      PN: WHT001189
      RUBBER RING
      from £2.16
      # 013
      PN: 001701592
      SPACER
      D I S T ANZ . GOMM . RAD I ATORE
      from £6.44
      # 014
      PN: 001701495
      RAD . SUPPOR
      ANELLO X SUPP.SERB.SUPPL.E RAD
      from £29.34
      SUPPLEMENTARY RESERVOIR BRACKE T RING & Genuine Lamborghini - New (to order)
      # 015
      PN: WHT001942
      WASHER
      ROND. D. 8, 5X32X2, 5
      from £1.77
      # 016
      PN: 001704296
      TANK CAP 1,0 BAR
      from £77.73
      MIURA COOLANT RESERVOIR PLUG Genuine Lamborghini - New (to order)
      # 017
      PN: 001729183
      COOLAN RESE
      SERBATOIO SUPPL. ACQUA
      from £250.65
      SUPPLEMENTARY COOLANT RESERVOI R Genuine Lamborghini - New (to order)
      # 018
      PN: 008830204
      CLAMP RING
      FASC. ROYAL A/5 7/11
      from £4.22
      # 019
      PN: 001710068
      PIPE
      TUBO SERB.SUPPL/RAD.SIN./C
      from £9.38
      LH RADIATOR/SUPPLEMENTARY RESE RVOIR PIP Genuine Lamborghini - New (to order)
      # 020
      PN: 008834501
      CLAMP
      FASCETTA VS .4456
      # 021
      PN: 001724298
      SLEEVE
      MANIC. COLLEG. RADI AT. ALLE TUBAZ
      from £28.50
      RADIATOR CONNECTING SLEEVE Genuine Lamborghini - New (to order)
      RADIATOR CONNECTING SLEEVE Genuine Lamborghini - Used in stock
      # 022
      PN: 001728258
      PIPE
      TUBO USC.ACQUA DA RAD.DS
      from £26.31
      COOLANT OUTLET PIPE FROM RH RA DIATOR Genuine Lamborghini - New (to order)
      COOLANT OUTLET PIPE FROM RH RA DIATOR Genuine Lamborghini - Used in stock
      # 023
      PN: WHT003040
      WASHER
      RONDELLA PORE/S
      from £4.06
      # 024
      PN: N 0211963
      NUT
      DADO N/70/105M
      from £1.04
      # 024
      PN: N0211963
      NUT
      DADO N/70/105M
      from £0.47
      # 025
      PN: 001728661
      FAN
      VENTOLA ASPIR.VS.VA01-AP6-36A
      from £329.67
      # 026
      PN: 001728738
      PIPE
      TUBO DAL 3 VIE AL RAD I AT. DX. FINO A VETT. N. 1435
      # 026
      PN: 001728833
      PIPE
      TUBO DAL 3 VIE AL RADIAT.DX. DALLA VETT. N. 1436
      from £27.53
      PIPE FROM THREE-WAY TO RH RADI ATOR Genuine Lamborghini - New (to order)
      # 027
      PN: 001710069
      PIPE
      TUBO SCAR. SERB. SUPPL. /C
      from £38.31
      SUPPLEMENTARY RESERVOIR DRAIN PIPE Genuine Lamborghini - New (to order)
      # 028
      PN: 008834501
      CLAMP
      FASCETTA VS. 4 45 6
      # 029
      PN: 008830204
      CLAMP RING
      FASC. ROYAL A/ 5 7/11
      from £4.22
      # 030
      PN: 001724300
      PIPE
      TUBO DAL TRE VIE AL SERB. SUPPL
      from £29.07
      PIPE FROM THREE-WAY TO SUPPLEM ENTARY RE Genuine Lamborghini - New (to order)
      # 031
      PN: 008100864
      BOLT
      BULLONE
      from £2.08
      # 032
      PN: 008400802
      WASHER
      ROND. 8X1 6X1, 5 RAME
      from £0.78
      COPPER WASHER 8.4X16X1.5 Genuine Lamborghini - New in stock
      # 033
      PN: 001728739
      PIPE
      TUBO DAL 3 VIE AL RADIAT.SX. FINO VETT. 1435
      from £110.00
      # 033
      PN: 001728834
      PIPE
      TUBO DAL 3 VIE AL RADIAT.SX. DA VETT. N. 1436
      from £27.53
      PIPE FROM THREE-WAY TO LH RADI ATOR Genuine Lamborghini - New (to order)
      # 034
      PN: 001728283
      PIPE
      TUBO USC.ACQUA DA RAD. SIN.
      from £94.01
      COOLANT OUTLET PIPE FROM LH RA DIATOR Genuine Lamborghini - New (to order)
      COOLANT OUTLET PIPE FROM LH RA DIATOR Genuine Lamborghini - Used in stock
      # 035
      PN: 001728294
      PIPE
      TUBO USC. RAD. SX/ 3 VIE P.H20
      from £197.30
      LH RADIATOR OUTLET/REAR THREE- WAY PIPE Genuine Lamborghini - New (to order)
      # 036
      PN: 001728275
      T. UNI
      TUBO 3 VIE SU POMPA ACQUA
      from £42.00
      THREE-WAY PIPE ON COOLANT PUMP Genuine Lamborghini - New (to order)
      THREE-WAY PIPE ON COOLANT PUMP Genuine Lamborghini - Used in stock
      # 037
      PN: 001728295
      PIPE
      TUBO 3VIE/POMPA ACQUA
      from £31.23
      THREE-WAY/COOLANT PUMP PIPE Genuine Lamborghini - New (to order)
      # 038
      PN: 001728737
      PIPE
      TUBO 3 VIE USC.ACQUA DAL TERM.
      from £53.84
      # 039
      PN: 001728845
      W RADIAT L
      RADIATORE ACQUA SIN. FINO VETT. N. 1435
      from £1,150.38
      # 039
      PN: 001728845
      RADIATOR
      RADIATORE SINISTRO DALLA VETT. N. 1436
      from £1,150.38
