Ferrari 575 Superamerica spare assembly units Parts Diagram

000 - spare assembly units

Ferrari 575 Superamerica Spare Assembly Units Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Price
# 001
MPN: 194305
COMPLETE TRANSMISSION
Not for F1
from £11,216.09
from £11,216.09
# 001
MPN: 194306
COMPLETE TRANSMISSION
Valid for F1
Supersession
Supersession
# 001
MPN: 221146
COMPLETE ENGINE
Not for GD
from £41,940.61
from £41,940.61
# 001
MPN: 221147
COMPLETE ENGINE
Valid for GD
from £34,126.59
from £34,126.59
# 001
MPN: 221149
PROPELLING UNIT SET OF GASKETS
from £937.87
from £937.87
