ferrari f430 spider (europe) racing seat- optional parts diagram

0133 - racing seat- optional

Ferrari F430 Spider (Europe) RACING SEAT- OPTIONAL Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                #
                                Part number
                                Description
                                Key
                                Price
                                # 001
                                MPN: 7141....
                                RH RACING SEAT
                                -Medium- -Leather Leather- -Not for USA, CDN, USA LIGHT-
                                RH RACING SEAT Genuine Ferrari Part - New (to order)
                                # 001
                                MPN: 7142....
                                RH RACING SEAT
                                -Large- -Leather Leather- -Not for USA, CDN, USA LIGHT-
                                Supersession
                                Supersession
                                Genuine Ferrari Part (no longer available to order)
                                # 001
                                MPN: 7143....
                                RH RACING SEAT
                                -Small- -Leather Leather- -Not for USA, CDN, USA LIGHT-
                                RH RACING SEAT Genuine Ferrari Part - New (to order)
                                # 001
                                MPN: 7144....
                                RH RACING SEAT
                                -Medium- -Leather Alcantara- -Not for USA, CDN, USA LIGHT-
                                RH RACING SEAT Genuine Ferrari Part - New (to order)
                                # 001
                                MPN: 7145....
                                RH RACING SEAT
                                -Large- -Leather Alcantara- -Not for USA, CDN, USA LIGHT-
                                RH RACING SEAT Genuine Ferrari Part - New (to order)
                                # 001
                                MPN: 7146....
                                RH RACING SEAT
                                -Small- -Leather Alcantara- -Not for USA, CDN, USA LIGHT-
                                RH RACING SEAT Genuine Ferrari Part - New (to order)
                                # 001
                                MPN: 7147....
                                RH RACING SEAT
                                -Leather Leather- -Applicable for USA, CDN-
                                Supersession
                                Supersession
                                Genuine Ferrari Part (no longer available to order)
                                # 001
                                MPN: 7148....
                                RH RACING SEAT
                                -Leather Alcantara- -Applicable for USA, CDN-
                                Supersession
                                Supersession
                                Genuine Ferrari Part (no longer available to order)
                                # 001
                                MPN: 7149....
                                RH RACING SEAT
                                -Leather Leather- -Applicable for USA LIGHT-
                                RH RACING SEAT Genuine Ferrari Part - New (to order)
                                # 001
                                MPN: 7150....
                                RH RACING SEAT
                                -Leather Alcantara- -Applicable for USA LIGHT-
                                Supersession
                                Supersession
                                Genuine Ferrari Part (no longer available to order)
                                # 001
                                MPN: 7151....
                                LH RACING SEAT
                                -Medium- -Leather Leather-
                                Supersession
                                Supersession
                                Genuine Ferrari Part (no longer available to order)
                                # 001
                                MPN: 7152....
                                LH RACING SEAT
                                -Large- -Leather Leather-
                                LH RACING SEAT Genuine Ferrari Part - New (to order)
                                # 001
                                MPN: 7153....
                                LH RACING SEAT
                                -Small- -Leather Leather-
                                LH RACING SEAT Genuine Ferrari Part - New (to order)
                                # 001
                                MPN: 7154....
                                LH RACING SEAT
                                -Medium- -Leather Alcantara-
                                LH RACING SEAT Genuine Ferrari Part - New (to order)
                                # 001
                                MPN: 7155....
                                LH RACING SEAT
                                -Large- -Leather Alcantara-
                                Supersession
                                Supersession
                                Genuine Ferrari Part (no longer available to order)
                                # 001
                                MPN: 7156....
                                LH RACING SEAT
                                -Small- -Leather Alcantara-
                                LH RACING SEAT Genuine Ferrari Part - New (to order)
                                # 002
                                MPN: 68832800
                                COMPLETE RH SEAT BELT
                                -Not for USA, CDN-
                                from £170.19
                                from £170.19
                                COMPLETE RH SAFETY BELTS Genuine Ferrari Part - New (to order)
                                # 002
                                MPN: 68832900
                                COMPLETE LH SEAT BELT
                                -Not for USA, CDN-
                                from £170.19
                                from £170.19
                                COMPLETE S.H. SAFETY BELTS Genuine Ferrari Part - New (to order)
                                # 002
                                MPN: 68867700
                                COMPLETE RH SEAT BELT
                                -Applicable for USA, CDN-
                                from £234.89
                                from £234.89
                                RH SEAT BELT Genuine Ferrari Part - New (to order)
                                # 002
                                MPN: 68867800
                                COMPLETE LH SEAT BELT
                                -Applicable for USA, CDN-
                                from £230.22
                                from £230.22
                                RAMO ARROTOLATORE 3PT COMPL. Genuine Ferrari Part - New (to order)
                                # 002
                                MPN: 810170..
                                COMPLETE RH SEAT BELT
                                -Coloured- -Not for USA, CDN-
                                Supersession
                                Supersession
                                Genuine Ferrari Part (no longer available to order)
                                # 002
                                MPN: 810171..
                                COMPLETE LH SEAT BELT
                                -Coloured- -Not for USA, CDN-
                                Supersession
                                Supersession
                                Genuine Ferrari Part (no longer available to order)
                                # 002
                                MPN: 810174..
                                COMPLETE RH SEAT BELT
                                -Coloured- -Applicable for USA, CDN-
                                Supersession
                                Supersession
                                Genuine Ferrari Part (no longer available to order)
                                # 002
                                MPN: 810175..
                                COMPLETE LH SEAT BELT
                                -Coloured- -Applicable for USA, CDN-
                                Supersession
                                Supersession
                                Genuine Ferrari Part (no longer available to order)
                                # 003
                                MPN: 81609500
                                UPPER LH SHELL, RH SEAT
                                UPPER LH SHELL RH SEAT Genuine Ferrari Part - New (to order)
                                # 003
                                MPN: 81609800
                                UPPER RH SHELL, LH SEAT
                                from £668.15
                                from £668.15
                                RH UPPER MOULDING FOR LH Genuine Ferrari Part - New (to order)
                                # 004
                                MPN: 80787500
                                PASSENGER SIDE BUCKLE MOUNT
                                from £48.24
                                from £48.24
                                PASSENGER SIDE BUCKLE BRANCH Genuine Ferrari Part - New (to order)
                                # 004
                                MPN: 80787800
                                DRIVER SIDE BUCKLE STALK
                                from £58.79
                                from £58.79
                                PILOT SIDE BUCKLE BRANCH Genuine Ferrari Part - New (to order)
                                # 005
                                MPN: 68636200
                                SCREW
                                from £0.98
                                from £0.98
                                SCREW Genuine Ferrari Part - New (to order)
                                # 006
                                MPN: 81033600
                                SEAT HOOK LEVER
                                from £87.81
                                from £87.81
                                SEAT RELEASE LEVER Genuine Ferrari Part - New (to order)
                                # 007
                                MPN: 14306321
                                SCREW
                                from £0.52
                                from £0.52
                                SCREW. Genuine Ferrari Part - New (to order)
                                SCREW (14306321) Genuine Maserati Part - New (to order)
                                # 008
                                MPN: 81200600
                                LOWER RH SHELL, LH SEAT
                                from £74.23
                                from £74.23
                                This part replaces part number 81126300
                                RH LOWER MOULDING Genuine Ferrari Part - New (to order)
                                # 008
                                MPN: 81202500
                                LOWER RH SHELL, RH SEAT
                                LOWER RH SHELL RH SEAT Genuine Ferrari Part - New (to order)
                                # 009
                                MPN: 13029026
                                SCREW
                                -Not for USA, CDN-
                                from £1.03
                                from £1.03
                                This part replaces part number 85429900
                                SCREW Genuine Ferrari Part - New In stock
                                # 009
                                MPN: 13029026
                                SCREW
                                -Applicable for USA, CDN-
                                from £1.03
                                from £1.03
                                This part replaces part number 85429900
                                SCREW Genuine Ferrari Part - New In stock
                                # 009
                                MPN: 81577500
                                SCREW
                                -Passenger side- -Applicable for USA, CDN-
                                from £0.47
                                from £0.47
                                This part replaces part number 14761627
                                SCREW -VALID FOR USA AND CDN Genuine Ferrari Part - New (to order)
                                # 010
                                MPN: 65806500
                                ELASTIC COLUMN
                                from £0.47
                                from £0.47
                                ELASTIC PLATE. Genuine Ferrari Part - New In stock
                                WASHER (65806500) Genuine Maserati Part - New (to order)
                                # 011
                                MPN: 81609600
                                RH SEAT RH UPPER GUARD
                                RH SEAT RH UPPER GUARD Genuine Ferrari Part - New (to order)
                                # 011
                                MPN: 81609900
                                UPPER LH SHELL, LH SEAT
                                from £668.15
                                from £668.15
                                LH UPPER MOULDING FOR LH Genuine Ferrari Part - New (to order)
                                # 012
                                MPN: 65806500
                                ELASTIC COLUMN
                                from £0.47
                                from £0.47
                                ELASTIC PLATE. Genuine Ferrari Part - New In stock
                                WASHER (65806500) Genuine Maserati Part - New (to order)
                                # 013
                                MPN: 81202400
                                LOWER LH SHELL, RH SEAT
                                from £185.59
                                from £185.59
                                LH SEAT LOWER LH CASING Genuine Ferrari Part - New (to order)
                                # 013
                                MPN: 81610000
                                LOWER LH SHELL, LH SEAT
                                LOWER LH SHELL LH SEAT Genuine Ferrari Part - New (to order)
                                # 014
                                MPN: 81034500
                                LH SEAT GUIDE
                                from £170.37
                                from £170.37
                                LH SEAT GUIDE Genuine Ferrari Part - New (to order)
                                # 015
                                MPN: 82783700
                                REGULATOR HANDLE
                                from £286.35
                                from £286.35
                                ADJUSTING KNOB Genuine Ferrari Part - New (to order)
                                # 016
                                MPN: 81034400
                                RH SEAT GUIDE
                                from £170.37
                                from £170.37
                                RH SEAT GUIDE Genuine Ferrari Part - New (to order)
                                # 017
                                MPN: 812617..
                                BUCKLE STALK SLEEVE
                                -Leather-
                                Supersession
                                Supersession
                                Genuine Ferrari Part (no longer available to order)
                                # 018
                                MPN: 67606400
                                CAP
                                from £34.92
                                from £34.92
                                PLUG. Genuine Ferrari Part - New (to order)
                                # 019
                                MPN: 66155100
                                COVER
                                from £3.29
                                from £3.29
                                SMALL COVER. Genuine Ferrari Part - New In stock
