007 - Timing chains

Ferrari 365 GTC4 (Mechanical) Timing chains Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                                                              #
                                                                                              Part number
                                                                                              Description
                                                                                              Price
                                                                                              # 001
                                                                                              MPN: 220482
                                                                                              SUPPORT
                                                                                              Supersession
                                                                                              Supersession
                                                                                              # 002
                                                                                              MPN: 220490
                                                                                              PIVOT
                                                                                              Supersession
                                                                                              Supersession
                                                                                              # 003
                                                                                              MPN: 220493
                                                                                              DRIVEN GEAR
                                                                                              Supersession
                                                                                              Supersession
                                                                                              # 004
                                                                                              MPN: 220492
                                                                                              CHAIN ​​DRIVEN GEAR
                                                                                              from £557.87
                                                                                              from £557.87
                                                                                              This part replaces part number 100198
                                                                                              # 005
                                                                                              MPN: 100207
                                                                                              GEAR FOR FIXED IDLER
                                                                                              from £300.51
                                                                                              from £300.51
                                                                                              # 006
                                                                                              MPN: 220498
                                                                                              PIVOT
                                                                                              Supersession
                                                                                              Supersession
                                                                                              # 007
                                                                                              MPN: 220629
                                                                                              SPACER
                                                                                              from £780.06
                                                                                              from £780.06
                                                                                              # 008
                                                                                              MPN: 100202
                                                                                              INGR.CONDOTTO SUALBERO DISTRIBUZ.
                                                                                              from £890.27
                                                                                              from £890.27
                                                                                              This part replaces part number 220494
                                                                                              # 009
                                                                                              MPN: 100195
                                                                                              CATENA COMANDO DISTRIBUZIONE
                                                                                              from £325.00
                                                                                              from £325.00
                                                                                              This part replaces part number 220505
                                                                                              # 010
                                                                                              MPN: 115984
                                                                                              CHAIN ​​SEALING SLIDE
                                                                                              from £163.58
                                                                                              from £163.58
                                                                                              This part replaces part number 100213
                                                                                              # 011
                                                                                              MPN: 220466
                                                                                              CENTRAL CHAIN ​​TENSIONER SLIDE
                                                                                              Supersession
                                                                                              Supersession
                                                                                              # 012
                                                                                              MPN: 100210
                                                                                              SIDE CHAIN ​​TENSIONER SLIDE
                                                                                              from £288.84
                                                                                              from £288.84
                                                                                              This part replaces part number 220474
                                                                                              # 013
                                                                                              MPN: 220468
                                                                                              ADJUSTABLE SKATE ASSEMBLY
                                                                                              from £340.61
                                                                                              from £340.61
                                                                                              # 013
                                                                                              MPN: 9220469
                                                                                              ADJUSTABLE SKATE
                                                                                              from £198.04
                                                                                              from £198.04
                                                                                              # 015
                                                                                              MPN: 114329
                                                                                              AUTOMATIC CHAIN ​​TENSIONER
                                                                                              from £236.84
                                                                                              from £236.84
                                                                                              This part replaces part number 100304
                                                                                              # 016
                                                                                              MPN: 10902321
                                                                                              BOLT
                                                                                              from £0.71
                                                                                              from £0.71
                                                                                              # 017
                                                                                              MPN: 10297860
                                                                                              GASKET
                                                                                              from £0.47
                                                                                              from £0.47
                                                                                              # 018
                                                                                              MPN: 100044
                                                                                              NUT
                                                                                              from £0.26
                                                                                              from £0.26
                                                                                              This part replaces part number 151230 - and 1 more. Click to view details
                                                                                              # 019
                                                                                              MPN: 11500021
                                                                                              THREADED STUD
                                                                                              from £9.50
                                                                                              from £9.50
                                                                                              # 020
                                                                                              MPN: 10516470
                                                                                              WASHER
                                                                                              Supersession
                                                                                              Supersession
                                                                                              # 021
                                                                                              MPN: 15896221
                                                                                              NUT
                                                                                              from £0.71
                                                                                              from £0.71
                                                                                              This part replaces part number 15896225
                                                                                              # 022
                                                                                              MPN: 101300
                                                                                              CASE FOR CHAIN ​​TENSIONER
                                                                                              from £8.63
                                                                                              from £8.63
                                                                                              # 023
                                                                                              MPN: 100015
                                                                                              SEALING RING
                                                                                              from £1.21
                                                                                              from £1.21
                                                                                              # 024
                                                                                              MPN: 101591
                                                                                              RING
                                                                                              from £12.69
                                                                                              from £12.69
                                                                                              # 025
                                                                                              MPN: 101298
                                                                                              BEARING
                                                                                              from £29.78
                                                                                              from £29.78
                                                                                              This part replaces part number 114762 - and 1 more. Click to view details
                                                                                              # 026
                                                                                              MPN: 101299
                                                                                              BEARING
                                                                                              Supersession
                                                                                              Supersession
                                                                                              # 027
                                                                                              MPN: 11080076
                                                                                              SEEGER RING
                                                                                              # 028
                                                                                              MPN: 101241
                                                                                              RING NUT
                                                                                              from £92.85
                                                                                              from £92.85
                                                                                              # 029
                                                                                              MPN: 10206320
                                                                                              Key
                                                                                              from £0.77
                                                                                              from £0.77
                                                                                              # 030
                                                                                              MPN: 10901921
                                                                                              BOLT
                                                                                              from £0.42
                                                                                              from £0.42
                                                                                              This part replaces part number 10901924 - and 1 more. Click to view details
                                                                                              # 031
                                                                                              MPN: 12344401
                                                                                              WASHER
                                                                                              # 032
                                                                                              MPN: 12574211
                                                                                              NUT
                                                                                              from £0.71
                                                                                              from £0.71
                                                                                              # 033
                                                                                              MPN: 100967
                                                                                              THREADED STUD
                                                                                              # 034
                                                                                              MPN: 95566
                                                                                              THREADED STUD
                                                                                              Supersession
                                                                                              Supersession
                                                                                              # 035
                                                                                              MPN: 11198074
                                                                                              WASHER
                                                                                              from £0.47
                                                                                              from £0.47
                                                                                              This part replaces part number 11198071 which we have in stock - and 4 more. Click to view details
                                                                                              # 036
                                                                                              MPN: 16100824
                                                                                              NUT
                                                                                              from £0.52
                                                                                              from £0.52
                                                                                              This part replaces part number 16100814 - and 1 more. Click to view details
                                                                                              # 037
                                                                                              MPN: 102704
                                                                                              DOWEL
                                                                                              from £1.59
                                                                                              from £1.59
                                                                                              This part replaces part number 500805
                                                                                              # 038
                                                                                              MPN: 100203
                                                                                              DRAG GRAIN
                                                                                              from £44.16
                                                                                              from £44.16
                                                                                              This part replaces part number 22449
                                                                                              # 039
                                                                                              MPN: 102827
                                                                                              DOWEL
                                                                                              from £38.09
                                                                                              from £38.09
                                                                                              This part replaces part number 22448
                                                                                              # 040
                                                                                              MPN: 102777
                                                                                              PLATE
                                                                                              from £7.84
                                                                                              from £7.84
                                                                                              This part replaces part number 4146781
                                                                                              # 041
                                                                                              MPN: 4146779
                                                                                              BOLT
                                                                                              from £10.68
                                                                                              from £10.68
                                                                                              # 042
                                                                                              MPN: 4146764
                                                                                              WASHER
                                                                                              from £28.72
                                                                                              from £28.72
                                                                                              # 043
                                                                                              MPN: 220510
                                                                                              PIVOT
                                                                                              Supersession
                                                                                              Supersession
                                                                                              # 044
                                                                                              MPN: LR 15 x 18 x 16,5
                                                                                              RING
                                                                                              # 046
                                                                                              MPN: 220656
                                                                                              PIVOT
                                                                                              Supersession
                                                                                              Supersession
