ferrari 365 gtb4 daytona (coachwork) quarter light frame & inner light parts diagram

022 - Quarter light Frame & inner light

Ferrari 365 GTB4 Daytona (Coachwork) Quarter light Frame & inner light Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Price
# 001
MPN: 4215200
SPESSORE ADEVISO P. PERNO MANIPLIA
03001334 Porta later. compl.
# 002
MPN: 20096806
MANIPLIA P. CRISTALLO PIREVOLE GD
03001334 Porta later. compl.
from £161.47
from £161.47
# 002
MPN: 20096905/A
MANIGLIA PER DEFLETTORE SINISTRO
from £130.71
from £130.71
# 003
MPN: 4229959
DOOR LOCK
03001334 Porta later. compl. - GD 30014005 - GS 30014104 Cristallo girevole compl.
from £138.31
from £138.31
# 004
MPN: 10353611
SCREW
03001334 Porta later. compl. - GD 30014005 - GS 30014104 Cristallo girevole compl.
# 005
MPN: 03001423
TELAINO CRISTALLO PIREVOLE
03001334 Porta later. compl. - GD 30014005 - GS 30014104 Cristallo girevole compl.
# 005
MPN: 30014005
QUARTER LIGHT FRAME
RHS
from £568.29
from £568.29
# 005
MPN: 30014104
QUARTER LIGHT FRAME
LHS
# 006
MPN: 20065009/a
RH FRONT QTR. GLASS RUBBER
(coupe only)
from £223.52
from £223.52
# 006
MPN: 200651008
PAIR QTR. GLASS RUBBERS
# 006
MPN: 20065108
LH FRONT QTR. GLASS RUBBER
from £223.52
from £223.52
# 007
MPN: 30253603
CRISTALLO GIREVOLE GD
03001334 Porta later. compl. - GD 30014005 - GS 30014104 Cristallo girevole compl.
from £1,787.45
from £1,787.45
# 007
MPN: 30253702
CRISTALLO GIREVOLE GS
03001334 Porta later. compl. - GD 30014005 - GS 30014104 Cristallo girevole compl.
from £2,681.18
from £2,681.18
# 008
MPN: 03007589
ROTATING CRYSTAL FRAME
03001334 Porta later. compl. - GD 30014005 - GS 30014104 Cristallo girevole compl.
# 009
MPN: 0300171
MOUSSE RUBBER PIECE WITH ROTATING GLASS
03001334 Porta later. compl.
from £10.16
from £10.16
# 010
MPN: 30039804
MODENATURA POSTER. (PIASTRINO) PORTA GD
03001334 Porta later. compl.
# 010
MPN: 30039903
MODENATURA POSTER. (PIASTRINO) PORTA GS
03001334 Porta later. compl.
from £23.36
from £23.36
# 011
MPN: 30040000
MODENATURA ANTER. (PIASTRINO) PORTA GD
03001334 Porta later. compl.
# 011
MPN: 30040109
MODENATURA ANTER. (PIASTRINO) PORTA GS
03001334 Porta later. compl.
# 012
MPN: 0300950
SCREW
03001334 Porta later. compl.
# 013
MPN: 0200646
SCREW
03001334 Porta later. compl.
# 014
MPN: 190118080
CARRUCOLA
03001334 Porta later. compl.
# 015
MPN: 12605370
WASHER
03001334 Porta later. compl.
Supersession
Supersession
# 016
MPN: 15896211
NUT
03001334 Porta later. compl.
Supersession
Supersession
This part replaces part number 15896210
# 017
MPN: 0300138
DESCENDING GLASS LOCKING CABLE
03001334 Porta later. compl.
# 018
MPN: 0300763
CABLE HARNESS FOR SIDE DOOR
03001334 Porta later. compl.
# 019
MPN: 0300764
MOLLETTE FISS. CAVO
03001334 Porta later. compl.
# 020
MPN: Luces L750
DOOR OPENING SIGNAL
03001334 Porta later. compl.
# 021
MPN: 17669011
SCREW
03001334 Porta later. compl.
