010 - timing
Ferrari 330 GT 2+2 Timing Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 22706
SCATOLA DISTRIBUZIONE
# 002
MPN: P 2
STUD
Supersession
Supersession
# 003
MPN: P 5
STUD
# 005
MPN: 12601279
WASHER
from £0.47
from £0.47
This part replaces part number 12601271 - and 2 more. Click to view details
# 006
MPN: 10257060
GASKET OR SEAL
from £0.47
from £0.47
This part replaces part number 10253060 - and 2 more. Click to view details
# 007
MPN: 100453
OIL THERMISTOR
from £13.71
from £13.71
This part replaces part number 100345 - and 1 more. Click to view details
# 008
MPN: 94901
STUD
from £1.24
from £1.24
# 009
MPN: P 2
STUD
Supersession
Supersession
# 010
MPN: 95920109
PRIGIONIERI FISSAGGIO SFIATI MOTORE ALLA SCATOLA
# 011
MPN: 17972
GASKET OR SEAL
Supersession
Supersession
# 012
MPN: 95920109
LONG THREADED STUD
# 014
MPN: 12601279
WASHER
from £0.47
from £0.47
This part replaces part number 12601271 - and 2 more. Click to view details
# 015
MPN: 22709
BEARING CAP LEFT AND RIGHT
# 016
MPN: 95920109
SHORT THREADED STUD
# 017
MPN: 22761
UNION
from £375.27
from £375.27
# 018
MPN: 22765
GASKET OR SEAL
from £3.58
from £3.58
# 019
MPN: 22777
TERMOSTATO MECANOSTAT
from £55.01
from £55.01
# 020
MPN: 95920109
STUD
# 021
MPN: 100044
NUT
from £0.26
from £0.26
This part replaces part number 151230 - and 1 more. Click to view details
# 022
MPN: 12601279
WASHER
from £0.47
from £0.47
This part replaces part number 12601271 - and 2 more. Click to view details
# 023
MPN: 95920109
STUD
# 024
MPN: 105557
SEAL
from £0.82
from £0.82
# 025
MPN: 92266
BOLT
from £23.45
from £23.45
# 026
MPN: 127496
WASHER
from £0.53
from £0.53
This part replaces part number 10516671 - and 2 more. Click to view details
# 027
MPN: 22505
WHEEL ON CAMSHAFT
from £402.89
from £402.89
# 028
MPN: 22575
WHEEL RETAINING FLANGE ON THE SHAFT
from £66.44
from £66.44
# 029
MPN: 22716
PIVOT
from £40.45
from £40.45
# 030
MPN: 22717
BUSSOLA PER INGRANAGGIO GALOPPINO
from £96.28
from £96.28
# 031
MPN: 95893001
GABBIA A RULLI
from £12.99
from £12.99
# 032
MPN: 22710
INGRANAGGIO PER GALOPPINO E TENDICATENA
from £1,174.09
from £1,174.09
# 033
MPN: 22718
DISTANZIALE PER INGRANAGGIO GALOPPINO
from £94.89
from £94.89
# 034
MPN: 105329
SEALING RING
from £1.45
from £1.45
# 035
MPN: 101591
RING
from £12.69
from £12.69
# 036
MPN: 22507
CATENA COMANDO DISTRIBUZIONE
(148 links)
from £435.66
from £435.66
# 037
MPN: 22712
PIVOT
from £87.98
from £87.98
# 038
MPN: 19
SEEGER RING
# 039
MPN: 22715
CORPO TENDITORE
# 040
MPN: 22725
SPRING
from £11.42
from £11.42
# 041
MPN: 22713
GASKET OR SEAL
from £0.60
from £0.60
# 042
MPN: 22711
SUPPORT
# 043
MPN: 22794
DISTANZIALE PER CORPO TENDITORE
from £5.34
from £5.34
# 044
MPN: 22724
GASKET OR SEAL
from £5.65
from £5.65
# 045
MPN: 22719
TAPPO PER TENDITORE
from £5.61
from £5.61
# 046
MPN: 22714
CUNEO BLOCCAGGIO TENDITORE
from £11.04
from £11.04
# 047
MPN: 106
SEAL
# 048
MPN: 94838
BOLT
from £5.55
from £5.55
# 049
MPN: 34371
BUSH
# 050
MPN: 34380
PUNTALINO COMANDO POMPA MECCANICA
from £45.26
from £45.26
# 051
MPN: 95860041
SEAL
Supersession
Supersession
# 052
MPN: 2037
SEAL
# 053
MPN: P 2
STUD
Supersession
Supersession
# 054
MPN: UNI 184
BOLT
# 055
MPN: UNI 184
BOLT
# 056
MPN: 10158700
EXPANSION PLUG
from £11.85
from £11.85
# 057
MPN: 95900412
NUT
from £6.36
from £6.36
This part replaces part number 92401
# 058
MPN: 8R 5
WASHER
Supersession
Supersession
# 059
MPN: 95850302
SEALING RING
from £25.77
from £25.77
# 059
MPN: MIM 4056
SEALING RING
not as spare part - use part number: 95850302
# 060
MPN: 93353
GASKET OR SEAL
Supersession
Supersession
# 061
MPN: 94844
UNION
from £1.92
from £1.92
# 062
MPN: P 2
LONG THREADED STUD
Supersession
Supersession
# 063
MPN: P 2
SHORT THREADED STUD
Supersession
Supersession
# 064
MPN: 95900412
NUT
from £6.36
from £6.36
This part replaces part number 92401
# 065
MPN: 8R 5
WASHER
Supersession
Supersession
# 066
MPN: 10405385
COPRIMORSETTO
from £2.50
from £2.50
This part replaces part number 100285 - and 2 more. Click to view details
# 067
MPN: 22108
GASKET OR SEAL
from £16.35
from £16.35
