ferrari 330 gtc / 365 gtc (coachwork) boot parts diagram

007 - BOOT

Ferrari 330 GTC / 365 GTC (Coachwork) Boot Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                  #
                                  Part number
                                  Description
                                  Price
                                  # 001
                                  MPN: 246-34-004-07
                                  TRUNK DOOR COMPLETE FRAMES AND COVERINGS - OVERALL
                                  from £876.49
                                  from £876.49
                                  # 001
                                  MPN: 246-34-004-365-CAL
                                  365 CALIFORNIA BOOT LID
                                  Valid for 365 California
                                  # 002
                                  MPN: 24-34-200-01
                                  SERRATURA SPORTELLO BAULE - COMPLESSIVO
                                  # 003
                                  MPN: 246-34-216-01
                                  RECEIPT FOR TRUNK DOOR LOCK
                                  from £1.82
                                  from £1.82
                                  # 004
                                  MPN: 134-28-198-00
                                  PROFILATO BATTUTA SPORTELLO BAULE (MM.3100)
                                  from £78.15
                                  from £78.15
                                  # 005
                                  MPN: 16316190
                                  BOOT RUBBER
                                  # 005
                                  MPN: 246-34-510-00
                                  COMMA BATTUTA SPORTELLO BAULE (MM.3100)
                                  (use part number: 16317190)
                                  Supersession
                                  Supersession
                                  # 006
                                  MPN: 246-34-070-01
                                  CERNIERA D. PER SPORTELLO BAULE - COMPLESS.
                                  from £183.75
                                  from £183.75
                                  # 006
                                  MPN: 246-34-071-01
                                  CERNIERA S. PER SPORTELLO BAULE - COMPLESS.
                                  from £183.75
                                  from £183.75
                                  # 007
                                  MPN: 246-34-460-03
                                  BARRA D. PER DISPOXITIVO APORTURA SOSTEGNO SPORTELLO POSTERIORE BAULE
                                  # 007
                                  MPN: 246-34-461-03
                                  L. BAR FOR REAR TRUNK DOOR SUPPORT OPENING DEVICE
                                  # 008
                                  MPN: 246-34-640-06
                                  FUEL PIPE PROTECTION
                                  # 009
                                  MPN: 46-34-084-00
                                  TRUNK DOOR BUFFER PLUG
                                  # 010
                                  MPN: 802-34-466-01
                                  FRONT RETAINER BATTLE DOOR SUPPORT OPENING DEVICE
                                  # 011
                                  MPN: 802-34-464-01
                                  REAR RETAINER TRUNK DOOR SUPPORT OPENING DEVICE
                                  # 012
                                  MPN: 242-34-486-08
                                  DISPOSITIVO BLOCCAGGIO RUOTA SCORTA COMPLESS.
                                  from £169.16
                                  from £169.16
                                  # 013
                                  MPN: 239-34-484-08
                                  SPARE WHEEL LOCKING FLANGE
                                  # 014
                                  MPN: 60307006
                                  Ferrari REAR SCRIPT
                                  Motif (3-Pin) - Metal Chrome type
                                  from £110.57
                                  from £110.57
                                  # 015
                                  MPN: 246-34-874-02
                                  ABBREVIATION 330 TRUNK
                                  from £85.48
                                  from £85.48
                                  # 016
                                  MPN: 246-34-630-00
                                  PIANETTO PER FONDO BAULE - COMPLESSIVO
                                  # 017
                                  MPN: 246-34-812-00
                                  RIPARO'SU SUPNORTO SERRATURA BAULE
                                  # 018
                                  MPN: 246-62-430-02
                                  HANDLE WITH BLOCK AND CHIME FOR TRUNK DOOR OPENING
                                  from £126.55
                                  from £126.55
                                  # 019
                                  MPN: 246-62-422-00
                                  CAVO COMANDO APORTUR.A BAULE CAN. GUAINA
